RUSHFPV Tank Plus 25-800mW 5.8GHz 37ch
Listed as: RUSHFPV Tank Plus 25-800mW 5.8GHz 37ch - MMCX
Of the 81 other 5.8 GHz analog video transmitters in our database, 31 have a lower maximum power than the Tank Plus 25-800mW 5.8GHz 37ch (800 mW, 29 dBm), 12 the same and 38 a higher one; the class median is 800 mW.
| System | analog |
|---|---|
| Max power | 800 mW |
| Frequency range | 5.8 GHz |
| Channels | 37 |
| Antenna connector | MMCX |
| Weight | 6.66 g |
| Price (approx.) | 39.99 USD |
RUSHFPV Tank Plus 25-800mW 5.8GHz 37ch VTX table for Betaflight
The band and channel frequencies and power levels as RUSHFPV publishes them for SmartAudio 2.1 control. Paste the CLI commands into Betaflight's CLI tab, or load the JSON file in Betaflight Configurator's Video Transmitter tab. How it works: setting up a VTX table in Betaflight.
| Band | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
|---|---|---|---|---|---|---|---|---|
| A BAND_A | 5865 | 5845 | 5825 | 5805 | 5785 | 5765 | 5745 | 5725 |
| B BAND_B | 5733 | 5752 | 5771 | 5790 | 5809 | 5828 | 5847 | 5866 |
| E BAND_E | 5705 | 5685 | 5665 | 5665 | 5885 | 5905 | 5905 | 5905 |
| F AIRWAVE | 5740 | 5760 | 5780 | 5800 | 5820 | 5840 | 5860 | 5880 |
| R RACEBAND | 5658 | 5695 | 5732 | 5769 | 5806 | 5843 | 5880 | 5917 |
Frequencies in MHz; "—" is an unused slot. Power levels: 25 (value 14), 200 (value 23), 500 (value 27), 800 (value 29).
vtxtable bands 5
vtxtable channels 8
vtxtable band 1 BAND_A A CUSTOM 5865 5845 5825 5805 5785 5765 5745 5725
vtxtable band 2 BAND_B B CUSTOM 5733 5752 5771 5790 5809 5828 5847 5866
vtxtable band 3 BAND_E E CUSTOM 5705 5685 5665 5665 5885 5905 5905 5905
vtxtable band 4 AIRWAVE F CUSTOM 5740 5760 5780 5800 5820 5840 5860 5880
vtxtable band 5 RACEBAND R CUSTOM 5658 5695 5732 5769 5806 5843 5880 5917
vtxtable powerlevels 4
vtxtable powervalues 14 23 27 29
vtxtable powerlabels 25 200 500 800
saveSource: https://drive.google.com/file/d/1zqBhxQWLQEZy1gKA4Y1bjwyu45-RZJjL/view — Copied from the maker's Betaflight file RUSH_TANK_ULTIMATE_PLUS_SA2.1_37CH.json in the RushFPV VTX Table Drive folder linked from rushfpv.net's Download Center. The 37CH (US) version restricts Band E by repeating a neighbour in the file (E4 = 5665, E7 = E8 = 5905) and carries no LOWRACE band; copied as published. Values are dBm as the maker's SmartAudio 2.1 file prints them (14 = 25 mW); labels are the file's. RushFPV publishes two files per model: this one and a 48-channel twin (RUSH_TANK_ULTIMATE_PLUS_SA2.1_48CH.json). The retail listing sells this board as the 37-channel version, so the 37CH file is the one stored.. Transmitting is only legal on the frequencies and power your country allows; see VTX frequency bands.
Choosing between systems? See analog vs DJI vs Walksnail vs HDZero.
